24 Station PVC Slipper Making Machine Rotary Air Blowing Slipper Machine Product Overview KT-618C

Name: 24 Station PVC Slipper Making Machine Rotary Air Blowing Slipper Machine Product Overview KT618C
Brand: KINGTOUR
Price: 15 USD

Wholesale 24 Station PVC Slipper Making Machine Rotary Air Blowing Slipper Machine Product Overview KT-618C from china suppliers

Place of Origin : GUANGDONG,CHINA

Brand Name : KINGTOUR

MOQ : 1 SET

Price : $15,900-23,900

Product name : PVC Slipper Making Machine

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Bearing, Gearbox, Motor, Pump

production capacity : 130-180 Pairs/hour

voltage : 380V/220V 3 Phase

power(w) : 18500

dimension(l*w*h) : 4960*3960*2360mm

warranty : 1 Year

key selling points : Easy to Operate

Function : To make PVC slipper

Raw material : PVC

Model : KT-618

Required labor : 1-2 workers

Finished Products : PVC slipper

Showroom Location : None

Marketing Type : New Product 2020

Warranty of core components : 1 Year

Condition : New

Applicable Industries : hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other

Weight : 5900

Certification : CE

Packaging Details : Professional safety export package

Delivery Time : 5-35 Days

Payment Terms : TT,LC,DP

Supply Ability : 100 Set Per Month

Contact Now

Product Overview

KT-618C Chinese Standard 24 Station Rotary PVC Slipper Air Blowing Molding Machine

This machine can make various kinds of slipper sandal flip flop and shoe with PVC material.

It only need 100 square meters and 2 workers, then you can start to make slipper sandal flip flop and shoe.

Product: Specialized in the production of full plastic slipper sandal shoe flip flop and sole etc.
Applicable material: Compact and expanded thermoplastic material, such as PVC PCU and TPR.

1. Computerization in analysis and design,the machine is well in stability.

2. The machine is controlled by PLC automatic control system and touch screen operation.Operation system has different language for different customer, such as English, Spanish, Portuguese and Vietnamese etc.

3. Conformed to human engineering in design, it features operational compatibility.

4. Number of various stations may be optionally chosen for small quantity but greater in variety, or mass production.

5. The well-interconnected oil circuit by electric control can reduce waiting time, quicken production rate, and promote productivity.

6. The multi-station mechanism is suitable for numerous molds to work in production line. It saves the time for the mold-change and extends the length of cooling time. The working efficiency is highly enhanced.

7. Specially designed, the oil pressure circuit board is simple in structure. The function description of various switches is clearly indicated.

8. It could be equipped with air blowing system and can produce light weight.

9. All new model,2 color machine only need one worker for operation.

10. Using different clamping force of 80T/100T/120T for different design and material, to achieve the best quality of product.

FEATURES AT A GLANCE

Specification of slipper making machine

Model: KT-618A

Production: 300-440 Pcs/Hour

Work station: 24 Station

Clamping force: 80/100/120 Ton

Screw diameter: 65 mm

Max. Injection volume: 650-1000 cm3

Heating power: 7 kw

Motor: 18.5 kw

Servo motor:15.7 kw

Power consumption: 12-15 kw/h

Temperature control: 4 section

Machine dimension: 4200*3800*2350 mm

Machine weight: 5900 kgs

Loading into a 20 feet container

24 Station PVC Slipper Making Machine Rotary Air Blowing Slipper Machine Product Overview KT-618C

Back elevation

Left elevation

Right elevation

Machine Video

Finished samples

Flip flop sample produced by our machine

You can send me your ideal design to us, we can customized the mold with your logo and other requirements.

Slipper sample produced by our machine

We have more than 10,000 designs in our sample room, please contact me for more designs.

Flip flop making machine

Rain boot making Machine

Plastic shoe making Machine

4 Station EVA Slipper Making Machine

6 Station EVA Slipper Making Machine

8 Station EVA Slipper Making Machine

1 color Sole Making Machine

2 color Sole Making Machine

3color Sole Making Machine

Static 2 Station Sole Making Machine

Static 3 Station Sole Making Machine

Static 4 Station Sole Making Machine

1 Color DIP shoe Making Machine

2 color DIP shoe Making Machine

PP insole Making Machine

PRODUCT CONFIGURATION

PLC+Full-touch screen operation

Imported control valve

Power saving of servo system

CONTAINER LOADING
